Ducati SS 800 - Page 54

Caratteristiche tecniche
Specifications
sezione / section
C 3
26
A
B
C
D
E
F
G
H
L
M
N
P
SuperSport 800 - M.Y. 2006 - edizione/edition 00
Front and Rear wheel
Front wheel nut M 25x1.5 63 * GREASE B
Rear wheel nut M 16x1.5 72 * GREASE B
Rear wheel cush drive pin M 14x1.25* 46 * LOCK 8
Rear chain sprocket nut M 10x1.25 46 * LOCK 2
Fuel Tank
Fuel level sensor M30x1.5 8 GREASE B
Fuel tank drain plug M 8x1.25 5 LOCK 6
Fuel breather hose clamp (tank inside) 1.5
Fuel hoses clamp (tank inside) 2.5
Fuel tank hinge bracket retaining screw M 6x1 9
Fuel tank plug fixing screw M 5x0.8 5
Fuel tank buffers fixing screw M 6x1 9
Exhaust
Exhaust pipe clamp screw M 8x1.25 23
Exhaust pipe to head nut M 8x1.25 24
Stainless steel plugs to exhaust pipes 1/8 gas 25
Exhaust silencer screw M 8x1.25 24
Screw securing bracket to silencer 23
Seat
Seat lock ring nut M 22x1.5 1 mm LOCK 3
Seat lock retaining screw M 5x0.8 2.5
Air intake/Oil breather
Filter box screw M 6x1 9
Throttle body mounting clip 1.5
Filter box union clamp 2.2
Oil breather tank hose clip 2.2
Pressure regulator bracket screw 5
Fuel system, Canister
Canister mount nut 9
Canister mount retaining screw M 6x1 2.5
Fairing
Fairing front stud bolt M 10x1.5 18 LOCK 2
Fairing rear stud bolt M 10x1.5 43 LOCK 2
Side panels front retaining screw M 6x1 5
Fairing stud bolt securing screw M 6x1 9
Rear grab handle retaining screw M 6x1 8 * LOCK 2
Fairing securing screw M 5x0.8 1.5
Front shield securing screw under headlight 1.8 mm
Side panels rear retaining screw M 5x0.8 1.5
Fairing jointing screw 2.5
Part Thread (mm) Nm tolerance ±10% Notes
