Caratteristiche tecniche
Specifications
sezione / section
C 3
27
A
B
C
D
E
F
G
H
L
M
N
P
SuperSport 800 - M.Y. 2006 - edizione/edition 00
*
critical point for dynamic safety. Tightening torque tolerance must be: ± 5% Nm.
Note
For product specifications and symbols, refer to “Product specifications” (Section A2).
Stand
Side stand plate screw M 10x1.5 43 LOCK 5
Side stand pivot nut M 8x1.25 26 LOCK 5
Screw securing stand cable guide on
crankcase
M 6x1 10
Side stand sensor retaining screw M 6x1 10
Frame
Engine to frame mounting bolt nut M 12x1.25 60* GREASE B
Oil cooler
Oil cooler nipple on cooler M 14x1.5 23
Oil cooler nipple on engine M 14x1.5 23
Oil cooler mounting bolt M 6x1 9
Oil hose union on radiator end with twin O-
ring
M 16x1.5 32 *
Oil hose union on casing end with twin O-ring M 16x1.5 32 *
Part Thread (mm) Nm tolerance ±10% Notes
