Edge-Core ES4524M-POE

Configuring the Switch
3-112
CLI – The following example configures LACP parameters for ports 1-8. Ports 1-4
are used as active members of the LAG; ports 5-8 are set to backup mode.
Console(config)#interface ethernet 1/1 4-135
Console(config-if)#lacp actor system-priority 3 4-150
Console(config-if)#lacp actor admin-key 120 4-151
Console(config-if)#lacp actor port-priority 128 4-153
Console(config-if)#exit
.
.
.
Console(config)#interface ethernet 1/8
Console(config-if)#lacp actor system-priority 3
Console(config-if)#lacp actor admin-key 120
Console(config-if)#lacp actor port-priority 512
Console(config-if)#end
Console#show lacp sysid 4-154
Channel Group System Priority System MAC Address
-------------------------------------------------------------------
1 32768 00-16-B6-F0-3B-EC
2 32768 00-16-B6-F0-3B-EC
3 32768 00-16-B6-F0-3B-EC
4 32768 00-16-B6-F0-3B-EC
5 32768 00-16-B6-F0-3B-EC
6 32768 00-16-B6-F0-3B-EC
7 32768 00-16-B6-F0-3B-EC
8 32768 00-16-B6-F0-3B-EC
Console#show lacp 1 internal 4-154
Port Channel: 1
-------------------------------------------------------------------------
Oper Key: 120
Admin Key: 0
.
.
.
