Link Layer Discovery Protocol
3-181
Displaying LLDP Local Device Information
Use the LLDP Local Device Information screen to display information about the
switch, such as its MAC address, chassis ID, management IP address, and port
information.
Web – Click LLDP, Local Information.
Figure 3-91 LLDP Local Device Information
CLI – This example displays LLDP information for the local switch.
Console#show lldp info local-device 4-231
LLDP Local System Information
Chassis Type : MAC Address
Chassis ID : 00-16-B6-F0-3B-EC
System Name :
System Description : 24-port 10/100/1000 + 2-port mini-GBIC Gigabit PoE Switch
System Capabilities Support : Bridge
System Capabilities Enable : Bridge
Management Address : 192.168.0.192 (IPv4)
LLDP Port Information
Port | PortID Type PortID PortDesc
----- + ---------------- ----------------- --------------------------------
Eth1/1 | MAC Address 00-16-B6-F0-3B-ED Ethernet Port on unit 1, port 1
Eth1/2 | MAC Address 00-16-B6-F0-3B-EE Ethernet Port on unit 1, port 2
Eth1/3 | MAC Address 00-16-B6-F0-3B-EF Ethernet Port on unit 1, port 3
Eth1/4 | MAC Address 00-16-B6-F0-3B-F0 Ethernet Port on unit 1, port 4
Eth1/5 | MAC Address 00-16-B6-F0-3B-F1 Ethernet Port on unit 1, port 5
.
.
.
