Edge-Core ES4524M-POE

Configuring the Switch
3-48
Web – Click SNMP, SNMPv3, Remote Users. Click New to configure a user name.
In the New User page, define a name and assign it to a group, then click Add to save
the configuration and return to the User Name list. To delete a user, check the box
next to the user name, then click Delete.
Figure 3-27 Configuring Remote SNMPv3 Users
CLI – Use the snmp-server user command to configure a new user name and
assign it to a group.
Console(config)#snmp-server user mark group r&d remote
192.168.1.19 v3 auth md5 greenpeace priv des56 einstien 4-73
Console(config)#exit
Console#show snmp user 4-74
No user exist
SNMP remote user
EngineId: 80000000030004e2b316c54321
User Name: mark
Authentication Protocol: none
Privacy Protocol: none
Storage Type: nonvolatile
Row Status: active
Console#
