Link Aggregation Commands
4-149
4
Command Usage
• When configuring static trunks, the switches must comply with the Cisco
EtherChannel standard.
•Use no channel-group to remove a port group from a trunk.
• Use no interfaces port-channel to remove a trunk from the switch.
Example
The following example creates trunk 1 and then adds port 11.
lacp
This command enables 802.3ad Link Aggregation Control Protocol (LACP) for the
current interface. Use the no form to disable it.
Syntax
[no] lacp
Default Setting
Disabled
Command Mode
Interface Configuration (Ethernet)
Command Usage
• The ports on both ends of an LACP trunk must be configured for full duplex,
and auto-negotiation.
• A trunk formed with another switch using LACP will automatically be assigned
the next available port-channel ID.
• If the target switch has also enabled LACP on the connected ports, the trunk
will be activated automatically.
• If more than eight ports attached to the same target switch have LACP
enabled, the additional ports will be placed in standby mode, and will only be
enabled if one of the active links fails.
Console(config)#interface port-channel 1
Console(config-if)#exit
Console(config)#interface ethernet 1/11
Console(config-if)#
