Configuring the Switch
3-104
Web – Click Port, Port Configuration or Trunk Configuration. Modify the required
interface settings, and click Apply.
Figure 3-55 Configuring Port Attributes
CLI – Select the interface, and then enter the required settings.
Console(config)#interface ethernet 1/13 4-135
Console(config-if)#description RD SW#13 4-136
Console(config-if)#shutdown 4-141
.
Console(config-if)#no shutdown
Console(config-if)#no negotiation 4-137
Console(config-if)#speed-duplex 100half 4-136
Console(config-if)#flowcontrol 4-139
.
Console(config-if)#negotiation
Console(config-if)#capabilities 100half 4-138
Console(config-if)#capabilities 100full
Console(config-if)#capabilities flowcontrol
Console(config-if)#exit
Console(config)#interface ethernet 1/23
Console(config-if)#media-type copper-forced 24-6
Console(config-if)#
