Configuring the Switch
3-22
To delete a file select System, File Management, Delete. Select the file name from
the given list by checking the tick box and click Apply. Note that the file currently
designated as the startup code cannot be deleted.
Figure 3-11 Deleting Files
CLI – Enter the IP address of the TFTP server, select “config” or “opcode” file type,
then enter the source and destination file names, set the new file to start up the
system, and then restart the switch.
.
Console#copy tftp file 4-24
TFTP server ip address: 10.1.0.19
Choose file type:
1. config: 2. opcode: <1-2>: 2
Source file name: v1000-18.bix
Destination file name: V1.0
\Write to FLASH Programming.
-Write to FLASH finish.
Success.
Console#config
Console(config)#boot system opcode:V1.0 4-28
Console(config)#exit
Console#reload 4-13
