Port Configuration
3-115
Web – Click Port, LACP, Port Internal Information. Select a port channel to display
the corresponding information.
Figure 3-60 Displaying Local LACP Port Information
CLI – The following example displays the LACP configuration settings and
operational state for the local side of port channel 1.
Console#show lacp 1 internal 4-154
Port Channel: 1
-------------------------------------------------------------------------
Oper Key: 120
Admin Key: 0
Eth 1/ 3
-------------------------------------------------------------------------
LACPDUs Internal: 30 sec
LACP System Priority: 32768
LACP Port Priority: 32768
Admin Key: 120
Oper Key: 120
Admin State: defaulted, aggregation, long timeout, LACP-activity
Oper State: distributing, collecting, synchronization,
aggregation, long timeout, LACP-activity
.
.
.
