Class of Service Configuration
3-189
Web – Click Priority, Traffic Classes. Assign priorities to the traffic classes (i.e.,
output queues), then click Apply.
Figure 3-93 Configuring Traffic Classes
CLI – The following example shows how to change the CoS assignments to a
one-to-one mapping.
* Mapping specific values for CoS priorities is implemented as an interface configuration
command, but any changes will apply to the all interfaces on the switch.
Console(config)#interface ethernet 1/1 4-135
Console(config-if)#queue cos-map 0 0 4-237
Console(config-if)#queue cos-map 1 1
Console(config-if)#queue cos-map 2 2
Console(config-if)#exit
Console(config)#exit
Console#show queue cos-map ethernet 1/1 4-239
Information of Eth 1/1
CoS Value : 0 1 2 3 4 5 6 7
Priority Queue: 0 1 2 1 2 2 3 3
.
.
.
