Edge-Core ES4524M-POE

Command Line Interface
4-176
4
Example
spanning-tree mst-configuration
This command changes to Multiple Spanning Tree (MST) configuration mode.
Default Setting
• No VLANs are mapped to any MST instance.
• The region name is set the switch’s MAC address.
Command Mode
Global Configuration
Example
Related Commands
spanning-tree spanning-disabled (4-179)
mst priority (4-177)
name (4-178)
revision (4-178)
max-hops (4-179)
mst vlan
This command adds VLANs to a spanning tree instance. Use the no form to remove
the specified VLANs. Using the no form without any VLAN parameters to remove all
VLANs.
Syntax
[no] mst instance_id vlan vlan-range
• instance_id - Instance identifier of the spanning tree. (Range: 0-4094)
• vlan-range - Range of VLANs. (Range: 1-4093)
Default Setting
none
Command Mode
MST Configuration
Command Usage
• Use this command to group VLANs into spanning tree instances. MSTP
generates a unique spanning tree for each instance. This provides multiple
pathways across the network, thereby balancing the traffic load, preventing
wide-scale disruption when a bridge node in a single instance fails, and
allowing for faster convergence of a new topology for the failed instance.
Console(config)#spanning-tree transmission-limit 4
Console(config)#
Console(config)#spanning-tree mst-configuration
Console(config-mstp)#
