Port Configuration
3-113
Displaying LACP Port Counters
You can display statistics for LACP protocol messages.
Web – Click Port, LACP, Port Counters Information. Select an interface port to
display the corresponding information.
Figure 3-59 Displaying LACP Port Counters
CLI – The following example displays LACP counters for port channel 1.
Table 3-4 LACP Port Counters
Field Description
LACPDUs Sent Number of valid LACPDUs transmitted from this channel group.
LACPDUs Received Number of valid LACPDUs received on this channel group.
Marker Sent Number of valid Marker PDUs transmitted from this channel group.
Marker Received Number of valid Marker PDUs received by this channel group.
Marker Unknown Pkts Number of frames received that either (1) Carry the Slow Protocols Ethernet
Type value, but contain an unknown PDU, or (2) are addressed to the Slow
Protocols group MAC Address, but do not carry the Slow Protocols Ethernet
Type.
Marker Illegal Pkts Number of frames that carry the Slow Protocols Ethernet Type value, but
contain a badly formed PDU or an illegal value of Protocol Subtype.
Console#show lacp 1 counters 4-154
Port Channel: 1
-------------------------------------------------------------------------
Eth 1/ 3
-------------------------------------------------------------------------
LACPDUs Sent: 310
LACPDUs Receive: 277
Marker Sent: 0
Marker Receive: 0
LACPDUs Unknown Pkts: 0
LACPDUs Illegal Pkts: 0
.
.
.
