Configuring the Switch
3-80
Web – Click Security, Port Security. Set the action to take when an invalid address is
detected on a port, set the maximum number of MAC addresses allowed on a port,
and click Apply.
Figure 3-40 Configuring Port Security
CLI – This example sets the command mode to Port 5, sets the port security action
to send a trap and disable the port, and then enables port security for the switch.
Console(config)#interface ethernet 1/5
Console(config-if)#port security action trap-and-shutdown 4-110
Console(config-if)#port security
Console(config-if)#
