Configuring the Switch
3-12
Web – Click System, System Information. Specify the system name, location, and
contact information for the system administrator, then click Apply. (This page also
includes a Telnet button that allows access to the Command Line Interface via Telnet.)
Figure 3-3 System Information
CLI – Specify the hostname, location and contact information.
Console(config)#hostname R&D 5 4-16
Console(config)#snmp-server location WC 9 4-64
Console(config)#snmp-server contact Geoff 4-63
Console(config)#exit
Console#show system 4-19
System Description: 24-port 10/100/1000 + 2-port mini-GBIC
Gigabit PoE Switch
System OID String: 1.3.6.1.4.1.259.8.1.7
System Information
System Up Time: 0 days, 0 hours, 7 minutes, and 22.65 seconds
System Name: R&D 5
System Location: WC 9
System Contact: Geoff
MAC Address (Unit1): 00-00-35-28-00-03
Web Server: Enabled
Web Server Port: 80
Web Secure Server: Enabled
Web Secure Server Port: 443
Telnet Server: Enable
Telnet Server Port: 23
Jumbo Frame: Disabled
POST Result:
DUMMY Test 1 ................. PASS
UART Loopback Test ........... PASS
DRAM Test .................... PASS
Timer Test ................... PASS
Done All Pass.
Console#
