Command Line Interface
4-230
4
Example
Console#show lldp config
LLDP Global Configuation
LLDP Enable : Yes
LLDP Transmit interval : 30
LLDP Hold Time Multiplier : 4
LLDP Delay Interval : 2
LLDP Reinit Delay : 2
LLDP Notification Interval : 5
LLDP Port Configuration
Port AdminStatus NotificationEnabled
-------- + ----------- -------------------
Eth 1/1 | Tx-Rx True
Eth 1/2 | Tx-Rx True
Eth 1/3 | Tx-Rx True
.
.
.
switch#show lldp config detail ethernet 1/1
LLDP Port Configuration Detail
Port : Eth 1/1
Admin Status : Tx-Rx
Notification Enabled : True
Basic TLVs Advertised:
port-description
system-name
system-description
system-capabilities
management-ip-address
802.1 specific TLVs Advertised:
*port-vid
*vlan-name
*proto-vlan
*proto-ident
802.3 specific TLVs Advertised:
*mac-phy
*poe
*link-agg
*max-frame
Console#
