9.6.3 Set the acquisition parameters for an ODS/Modal job
1. From the ODS/Modal main menu, press F8 Job Manager.
2.
Use the up and down arrow keys to select a job.
3. Press F4 Edit This Job > F8 Analysis Setup.
4. Set up the following options as necessary.
Option Description
F2 Set Spectra Params Set the Fmax, Fmin, and lines of resolution. See Section 6.7.1 and
Section 6.7.2.
F3 Set Averaging Set the type of averaging, the number of averages to collect, and the
acquisition mode. See Section 6.7.4.
F4 Set Window Set the type of window to use. See Section 6.7.3.
F7 Tach Setup Set up a tachometer.
F9 Set Trigger Select the type of trigger to use to start the measurement. See
Section 6.7.6.
F12 Input Setup Set up the input channels, the sensor type, and the units for the
acquisition type. See Section 9.3.1.
5. Press Enter.
Save the acquisition parameter setup in ODS/Modal
1.
From the ODS/Modal main menu, press F8 Job Manager.
2. Press F4 Edit This Job > F8 Analysis Setup > F6 Save / Recall Setup.
3. Use the up and down arrow keys to select a setup.
You may see several listed as Empty.
4. Press F2 Store Setup.
5. Enter up to 20 characters for the name.
6. Press Enter.
Open a saved acquisition parameter setup in ODS/Modal
If you saved your setup for the Analysis Setup option, you can open and use that setup.
Procedure
1. From the ODS/Modal main menu, press F8 Job Manager.
2. Use the up and down arrow keys to select a job.
3. Press F4 Edit This Job > F8 Analysis Setup > F6 Save / Recall Setup.
4. Use the up and down arrow keys to select a saved setup.
You can also press F5 Recall Default Setup.
ODS/Modal
MHM-97432 Rev 7 289
