354 Eos Family Operations Manual
Effect on an Effect/ Intensity Master Submaster
Pressing the bump button starts the effect. The fader controls the rate and/ or size based on the
effect’s entry behavior. Pressing the bump button again stops the effect.
In other words, there is no difference between a proportional fader and an intensity master when the
submaster is configured to be an effect submaster.
Global Effects Fader
A fader can be mapped as global effects in the fader configuration display, [Tab] [3][6]. This fader
type is used to master all effects or specific effects based off of the current filtering applied to the
fader.
Note: You can use multiple global effects faders.
The following filters can be applied to effects running on:
Cue lists - you can specify certain cue lists or select {All} or {None}. Not available on Element 2.
Submasters - you can specify certain submasters or select {All} or {None}.
Channels - you can specify certain channels that will be affected by the global effects
fader.See Channel and Parameter Filters on Faders (on page94)
Parameters - you can specify certain parameters that will be affected by the global effects
fader.See Channel and Parameter Filters on Faders (on page94)
Effects - you can specify certain effects or select {All} or {None}.
Manual- when on, the global effects fader will only affect manually run effects. By default,
this is off.
Note: If no filters have been applied, the fader will master all effects.
Fader Options
The following fader options are available for a global effects fader:
Effect Rate - fader centers to home. It controls the rate of any running effects (same behavior
as using rate via the Effect Status Display). Min is 0, and Max is 200.
Effect Size - similar to Effect Rate but for effect size. Min is 0, and Max is 200.
Fader Disabled - no action is assigned to the fader.
Effect Master - masters the entry/ exit mode of the effects (size, rate or both).
Button Options
The following options are available for global effect buttons:
Bump - plays back the effect at 100% of the recorded level. It will continue to do so until
released.
Freeze- halts all effect activity on the fader.
Start Stop Effect -starts the effect while ignoring dwell times. Will stop effects if any are run-
ning.
