Show Control 499
{String TX Source Name}
Allows the user to specify a list of specific comma separated names of devices to send strings tom
for example, for use with Paradigm.
{String TX Port}
Setting for the UDP destination port that the console will send strings.
{String TX IP Address}
Sets the destination IP address or ACN devices supporting the ACN String EPI that the console will
use to send strings. This can contain either an IP address for UDP string destinations or ACN device
names.. A combination of UDP and ACN devices are not supported. Please see String Interface (on
page523)for more specific configuration information.
{String MSC TX}
When enabled, this setting will cause the console to send serial strings when certain actions happen
at the console. See Sending From User Events (on page528).
Port Setup Options
Eos Ti, Gio, Eos RPU3, Gio @5, Ion Xe, Element 2, Ion, Ion RPU, Element, and Eos Programming Wing
have additional ports and connectors located on the rear panel for show control. Additional setup
options for these ports and connectors are in the ECU>{Settings}>{Local I/O} and in ECU>{Settings}>
{Network} .
Note: The built-in I/O ports on these devices will not broadcast information over the net-
work and are only used in a local console system.
MIDI Rx and MIDI Tx Group IDs
Allows you to set the group number for the MIDI In and MIDI Out ports. Group numbers can be from
1-32. Default for both ports is 1.
To receive MIDI from the built-in ports, the ACN MIDI Rx ID in Setup>{System}>{ShowControl} must
match the MIDI Rx Group ID in the ECU. To transmit MIDI from the local ports, the ACN MIDI Tx ID in
Setup>{System}>{ShowControl} must match the MIDI Tx Group ID in the ECU.
Note: While Gio@5 has contact closure ports, it does not have local MIDI ports. A Show
Control gateway is required for MIDI input.
Contact Closure (remote trigger connector)
Allows you to set the Group and Address In values for the remote trigger input on the back of your
console. The contact closure only reports on/off even though it is considered an analog input.
Note: The contact closures require DC voltage, which is supplied by the console on pins
14+15. See the diagram in Relay Out (remote trigger connector) (on the next page).
