534 Eos Family Operations Manual
Message Structure
Please see Hexadecimal and MIDI Show ControlFormatting (on page520) for more information on
the show control message structures.
Options
The following options are available:
{Commands}
Go, Stop, Resume - represents triggering a cue, stopping a cue, and resuming a cue, respect-
ively. The following fields are available:
Device ID - the MIDI Show Control device ID that should respond to the message
List ID - the cue list
ID - the cue number
Set - represents controlling a fader. The following fader targets are available:
Subs
Grandmaster
Master Fader Up- the level of the Up fader on the master playback pair
Master Fader Down - the level of the Down fader on the master playback pair
The following fields are available for the fader targets:
Device ID – the MIDI Show Control device ID that should respond to the message
ID (subs only) – the number of the submaster fader
Level – the specified level of the fader from 0-100% (0-127 decimal, 00-7F hex)
Fire – represents executing a macro. The following fields are available:
Device ID – the MIDI Show Control device ID that should respond to the message
ID - the macro number to be fired
Creating a MIDI Event List and Event
Open the Show Control Display
[Displays]>[More SK]>{Show Control}
Create a new Event List and choose the Network type
<Event> [6] [/] {Type} {Network} [Enter]
Enable the list to respond to {External} sources
<Event> [6] [/] {External} [Enter]
Creating a Note On Event
Create a new event and open the MIDI String configuration screen
<Event> [1] [More SK] {MIDI String}
Select the {NoteOn} type
