52 Eos Family Operations Manual

Resize Frames

Select this icon to resize frames in any of the workspaces on the monitor. After selecting, resizing

tools will appear between frames of the workspace and you can select and drag the resize tool icons

to adjust sizing as needed.

Monitor Mapping

Select this icon to arrange your monitors without having to go into the ECU. This function allows you

better control of your snapshots (About Snapshots (on page398)).

Click on a monitor to display the available numbers, and then click on the number to assign it.

Note: On-board touchscreens are locked, and their arrangement cannot be changed.

Note: A left to right arrangement is recommended.
