446 Eos Family v2.9.0 Operations Manual
Relay Outputs
Eos Family consoles can trigger relay outputs on Net3 I/O Gateways and on the built-in relay
output (when available). Relay outputs are also often called remote triggers, contact closures, or
contact outputs. Relay outputs are controlled by external links in cues and submasters only.
Note: You enter relay information in the live or blind displays. This is not a Show
Control display function.
Example:
[Live] [Cue] [1] {Execute} {Relay} [1] [/] [2] {On} [Enter] - 1 is the ACN Group ID
of the I/O Gateway or built-in relay output and the 2 is the relay output address.
