400 Eos Family v2.9.0 Operations Manual
With the devices synchronized with the Primary, install the new version of software onto the
Primary. All devices will lose their connection with the Primary at that time. When the Primary
comes back online after installing the software, all the connected devices will be forced to
update their software before they can reconnect with the Primary.
Remote Power On/Off
In a multi-console system, it is possible to power on and off devices remotely. Remote Power On
and Remote Power Off must be enabled on each device before it can receive the power on and
off commands. In the ECU go to Settings> Network> Enable Remote Power Off and Enable
Remote Power On. The default setting for both is “Disabled”.
Note: Original Eos consoles cannot be remotely powered on.
The Remote Power commands are sent from the browser. The command for Power On is sent
from Browser> Network> Power On MultiConsole System, and the command for Power Off is
from Browser> Network> Power Off MultiConsole System.
Note: Only devices that synchronize with the Primary will be available for Remote
Power On and Off.
Mirror Mode
Mirror Mode is used to mirror the displays of another device. When a device is in mirror mode,
the only action allowed from that device is paging via the page keys and shut down/start up.
When a device in mirror mode pages, it also pages the host.
Mirror mode is intended primarily to allow a designer or assistant to see the exact same displays
as a programmer on the system. It can be used on any device on the network, including the
primary processor. Any device being mirrored is referred to as the Host.
The is no limit to the number of mirrored devices a host can have. But a console currently in
mirror mode cannot be mirrored.
A device that is currently in mirror mode can select which user number it is mirroring by using
the alphanumeric keyboard shortcut ALT+F1 + # (# being the user number). ALT + F2 can be
used to leave mirror mode.
Note: If a device is not currently in mirror mode, pressing M on an alphanumeric
keyboard will post Macro to the command line.
Using Mirror Mode on a Client without a Dongle
A client without a dongle can connect to the network. When this is done, the client can only
operate in mirror mode, and it will always connect to the primary processor. No other options
will be available.
Configuring Mirror Mode
Configuring a device to connect in Mirror mode is done from the Displays menu in the Browser.
When [Displays] is pressed, a {Mirror} softkey will be displayed. Pressing {Mirror} will open up a
list of potential hosts in the CIA.
