492 Eos Family v2.9.0 Operations Manual
Hardware
MIDI
Connections
MIDI Show
Control (MSC)
MIDI Time
Code (MTC)
MIDI Notes SMPTE
Wing Wing
Eos
Programming
Wing
Yes, In/Out
Local
In/Out
Also via SC GW
Local
In Only Also
via SC GW
Local
Out Only Also
via SC GW
Via SC GW
In Only
Net3 Show
Control GW
Yes
In/Out/Thru
Yes In/Out Yes In Only Yes Out Only Yes In Only
Net3 I/O GW n/a n/a n/a n/a
Analog Contact Closure Relay Out RS-232
UDP
Strings
Eos Titanium (Ti)
Via I/O
GW
4 closures,
others via I/O
1 local SPDT,
others via I/O
Via I/O
GW
Rx &
Tx
Eos Console
Via I/O
GW
Via I/O GW Via I/O GW
Via I/O
GW
Rx &
Tx
Eos RPU
Via I/O
GW
Via I/O GW Via I/O GW
Via I/O
GW
Rx &
Tx
Gio
Via I/O
GW
4 closures,
others via I/O
1 local SPDT,
others via I/O
Via I/O
GW
Rx &
Tx
Gio @ 5
Via I/O
GW
4 closures, oth-
ers via I/O
1 local SPDT, oth-
ers via I/O
Via I/O
GW
Rx &
Tx
Ion
Via I/O
GW
4 closures,
others via I/O
1 local SPDT,
others via I/O
Via I/O
GW*
Rx &
Tx
Ion RPU & Eos Family RPU3
Via I/O
GW
4 closures,
others via I/O
1 local SPDT,
others via I/O
Via I/O
GW*
Rx &
Tx
ETCnomad (PC/Mac) and
ETCnomad Puck
Via I/O
GW
Via I/O GW Via I/O GW
Via I/O
GW
Rx &
Tx
Eos Programming Wing
Via I/O
GW
4 closures,
others via I/O
1 local SPDT,
others via I/O
Via I/O
GW
n/a
Element
Via I/O
GW
4 closures,
others via I/O
1 local SPDT,
others via I/O
Via I/O
GW
Rx &
Tx
Net3 Show Control GW n/a n/a n/a n/a n/a
Net3 I/O GW
Yes
24 shared circuits- analog or
digital
Yes 16 SPDT
relays
Yes
n/a
*Ion consoles that have a DVI splitter and any Ion RPU have a local RS-232 port that is not
enabled. For questions, please contact ETC Technical Services. See Help from ETC Technical
Services (on page1) to find the office closest to you.
