System Basics 61
Target
This setting allows you to map a submaster, intensity, focus, color, or beam palette, preset,
global effect fader, manual time master, or grandmaster to a fader.
ID
This sets the number of the target assigned to the fader, such as Preset 2 or Submaster 5. For a
list of available Target IDs, click or press the {...} button beside ID.
Note: Content can also be loaded to faders from Live, using the command line and
load.
Size
A fader can be mapped so its content takes up 1, 2, or 3 faders. 1x will take up 1 fader, 2x will
use 2 faders, and 3x will use three.
Note: If a fader is mapped to 1x, the top button will be locked as a load button.
When mapped to 2x or 3x, the top left button will be locked as a load button.
Buttons &Slider
When set to Default Mapping, the button and fader configuration is drawn initially from the
submaster list properties for that content. If changes are made to that mapping in Tab 36, it
filters BACK to the submaster list and changes any other instances where that content is
mapped. If set to Local, any changes made in Tab 36 impact only that instance of the content.
See
Submaster Properties
for more information on default mapping.
Target List
If temporary fader mapping is being used, the list of content will display here. See
Temporary
Fader Mapping (on page215)
for more information.
Additional Configuration
Clicking on the configuration box will open additional configuration options that are dependent
on the target type assigned to the fader.
For detailed information on these various options, please see the following topics:
