Programming manual.
CNC 8070
·18·
(REF: 1709)
Ref. 0801
Ref. 0809
Ref. 0811
Ref. 0907
Ref. 1007
Software V03.20
Set change. The CNC lets change the gear of the slave axis or spindle of a
tandem.
Coordinate latching with the help of a probe or a digital input. • Variables: (V.)A.LATCH1.xn
(V.)A.LATCH2.xn
Status of the local probes. • Variables: (V.)G.PRBST1 (V.)G.PRBST2.
Axis synchronization. Managing a rotary axis as an infinite axis making it
possible to increase the feedback count of the axis indefinitely (wihout limits)
regardless of the value of the module.
• Variables: (V.)A.ACCUDIST.xn
Show a warning and interrupt program execution. • Instruction: #WARNINGSTOP.
Electronic cam programming (theoretical coordinates). • Instruction: #TCAM.
Dynamic distribution of the machining operations between channels. • Instruction: #DINDIST.
The CNC can park the main axes.
The axes may be programmed using the "?" wild card that refers to the axis
position in the channel.
• Wild card "?".
Functions G130 (percentage of acceleration) and G132 (percentage of jerk)
may be applied to the spindles.
• Functions G130 and G132.
Interface related variables.
Software V04.00 (it does not include the features of version V03.21)
Unicode.
Cancel spindle synchronization after executing M02, M30 or after an error or
a reset.
• Instructions #SYNC and #TSYNC.
Positioning a turret magazine whether there is a tool in the indicated position
or not.
• #ROTATEMZ instructions.
A channel maintains its master spindle after executing M02, M30 or after an
emergency or a reset or restarting the CNC.
• #MASTERinstruction.
Force the change of gears and/or of the parameter set of a Sercos drive • Variable: (V.)A.SETGE.xn
Set a machine coordinate. • Function G174.
There can now be up to 99 zero offsets. • Function G159.
There can now be up to 100 synchronization marks. • Instructions #MEET, #WAIT and #SIGNAL.
Select a turret position. • #ROTATEMZ instructions.
Axis synchronization. Managing a rotary axis as an infinite axis making it
possible to increase the feedback count of the axis indefinitely (wihout limits)
regardless of the value of the module.
• Variables: (V.)A.PREVACCUDIST.xn
Variables. The variable (V.)E.PROGSELECT can be written via part-program,
PLC and interface. This variable can only be written with the value of ·0·
• Variables: (V.)E.PROGSELECT
Variables. The following variables are valid for the spindle. • Variables: (V.)A.MEAS.sn
(V.)A.ATIPMEAS.sn
(V.)A.MEASOF.sn
(V.)A.MEASOK.sn
(V.)A.MEASIN.sn
Handwheels. Number of pulses sent by the handwheel since the system was
started up.
• Variables: (V.)G.HANDP[hw]
Feed handwheel.
Software V03.21 (features not included in version V04.00)
There can now be up to 1024 PLC messages. • PLC resources: MSG.
There can now be up to 1024 PLC errors. • PLC resources: ERR.
Software V04.01
Define the maximum acceleration and jerk allowed on the tool path. • Variables: (V.)G.MAXACCEL
(V.)G.MAXJERK
Variable to know the following error (lag) when feedback combination is active. • Variables: (V.)A.FLWE.xn
(V.)A.FLWACT.xn
Variable to know the position value of the first feedback when feedback
combination is active.
• Variable: (V.)A.POSMOTOR.xn
Software V04.10 (it does not include the features of version V04.02)
New languages (Russian and Czech). • Machine parameter: LANGUAGE.
Cancel the inclined plane on start-up. • Machine parameter: CSCANCEL.
M functions with an associated subroutine.
The CNC admits function G174 for axes in DRO mode and spindles. • Function G174.
Detailed CNC status in jog mode. • Variable: (V.)G.CNCMANSTATUS
Detailed CNC status in automatic mode. • Variable: (V.)G.CNCAUTSTATUS
Know the axes selected for home search, repositioning, coordinate preset or
movement to a coordinate.
• Variable: (V.)G.SELECTEDAXIS
