Programming manual.
CNC 8070
·19·
(REF: 1709)
Ref. 1010
Ref. 1107
Ref. 1304
Know the current position of the main rotary axes of the kinematics (third axis). • Variable: (V.)G.POSROTT
Know the target position of the main rotary axes of the kinematics (third axis). • Variable: (V.)G.TOOLORIT1
(V.)G.TOOLORIT2
Cancel the name change for axes and spindles (#RENAME) after executing
M02 or M30, after a reset or at the beginning of a new part-program in the same
channel.
• #RENAME instruction.
Software V04.02 (features not included in version V04.10)
New language (Russian). • Machine parameter: LANGUAGE.
The CNC admits function G174 for axes in DRO mode and spindles. • Function G174.
Detailed CNC status in jog mode. • Variable: (V.)G.CNCMANSTATUS
Detailed CNC status in automatic mode. • Variable: (V.)G.CNCAUTSTATUS
Know the axes selected for home search, repositioning, coordinate preset or
movement to a coordinate.
• Variable: (V.)G.SELECTEDAXIS
Know the current position of the main rotary axes of the kinematics (third axis). • Variable: (V.)G.POSROTT
Know the target position of the main rotary axes of the kinematics (third axis). • Variable: (V.)G.TOOLORIT1
(V.)G.TOOLORIT2
Know the status of a cam. • Variable: (V.)G.CAMST[cam]
Modify the range of the slave axis when activating the cam. • Variable: (V.)G.CAM[cam][index]
Set 0% feedrate override via PLC. • Variable: (V.)PLC.FRO
Cancel the name change for axes and spindles (#RENAME) after executing
M02 or M30, after a reset or at the beginning of a new part-program in the same
channel.
• #RENAME instruction.
Software V04.11
Synchronized switching. • Variables: (V.)G.TON
(V.)G.TOF
(V.)G.PON
(V.)G.POF
• Statement: #SWTOUT
Software V04.20
Maximum safety limit for feedrate. • Machine parameter: FLIMIT.
Maximum safety speed limit. • Machine parameter: SLIMIT.
Interruption subroutines per channel. • Programming instructions: #REPOS.
There may be up to 30 OEM subroutines per channel now (G180-G189 / G380-
G399).
The OEM subroutines may be executed either in a non-modal (G180, G181,
etc) or in a modal way (MG180, MG181, etc).
The operation of M19 with subroutine has changed. • Function: M19.
Know the status of a cam. • Variable: (V.)G.CAMST[cam]
Modify the range of the slave axis when activating the cam. • Variable: (V.)G.CAM[cam][index]
Set 0% feedrate override via PLC. • Variable: (V.)PLC.FRO
Detailed CNC status in automatic mode. New values. • Variable: (V.)G.CNCAUTSTATUS
Active zero offset. • Variable: (V.)G.EXTORG
The CNC can execute programs of the 8055 MC and 8055 TC models made
up with conversational canned cycles including geometric assistance.
Software V04.21
New model LCD-10K. • Variables: (V.)MPMAN.JOGKEYDEF[jk]
(V.)MPMAN.USERKEYDEF[uk]
Software V04.22
Set the zero offsets with a coarse part and a fine part. • Variables: (V.)A.ADDORG.xn
(V.)A.COARSEORG.xn
(V.)A.FINEORG.xn
(V.)A.COARSEORGT[nb].xn
(V.)A.FINEORGT[nb].xn
Cancel mirror image (G11/G12/G13/G14) after M30 and reset.
Software V04.24
Additional negative command pulse for analog axes. • Variable: (V.)MPA.BAKANOUT[set].xn
The SPDLEREV mark (reverse turning direction) affects the spindle in M19. • Variable: (V.)MPA.M19SPDLEREV.xn
Functions M02, M30 and reset do not cancel the speed limit function G192. • Function G192.
Functions M02, M30 and reset do not cancel the constant surface speed (CSS)
function.
• Function G96.
Software V04.10 (it does not include the features of version V04.02)
