SET UP EDITOR MENU
SET UP MV MENU
SET UP STATUS MENU
KEYER KEYER EDGE
KEYER KEYER AUTO CK
KEYER KEYER MATT
KEYER KEYER GAIN/CLIP
KEYER KEYER POS/SIZE
KEYER KEYER CROP
KEYER KEYER BORDER
KEYER KEYER SUB EFF
DSK DSK EDGE
DSK DSK MATT
DSK DSK GAIN/CLIP
DSK DSK POS/SIZE
DSK DSK CROP
DSK DSK BORDER
DSK DSK SUB EFF
PinP PinP 1 XPT
PinP PinP 2 XPT
STILL STILL
MATT MATT
 If Function Type is Set:
Turn F2 to select the type of function and press F2. Then turn F3 to select a function to be used
and press F3. Once the function is assigned to a User button, pressing the button switches the
assigned function On and Off. If a function is assigned, it can also be a menu shortcut
(accessible by pressing the button twice quickly).
Assignable Functions
When MARKR (Marker) was selected for the TYPE item:
Setting Function Button Indication
PGM ENABLE
Pressing the button shows a safety area marker for
the output.
ON: Lit orange,
OFF: Unlit
AUX1 ENABLE
AUX2 ENABLE
SLOT-C CH1 ENABLE
SLOT-C CH2 ENABLE
SLOT-D CH1 ENABLE
SLOT-D CH2 ENABLE
When GPIO (GPI In/Out) was selected for the TYPE item:
Setting Function Button Indication
GPI IN ENABLE Pressing the button enables GPI IN.
ON: Lit orange,
OFF: Unlit
GPI OUTPUT1-12
(PUSH)
The GPI OUTPUT function (1-12) represents
ON/OFF setting for each GPI OUTPUT (1-12)
assigned to a GPI IN/TALLY OUT connector pin set
at the menu.
The function is enabled whenever the relevant
USER button is pressed.
Lit when pushed,
unless unlit.
GPI OUTPUT1-12
(TGLE)
The GPI OUTPUT function (1-12) represents
ON/OFF setting for each GPI OUTPUT (1-12)
assigned to a GPI IN/TALLY OUT connector pin set
at the menu.
The function is enabled whenever the relevant
USER button is pressed.
ON: Lit orange,
OFF: Unlit
