Machine Components
37
Product Overview
2
îš„Duplex automatic document feeder (optional)
Note • In this guidebook, Duplex Auto Document Feeder (Optional) is referred to as Document
Feeder.
No. Component Function
1 Confirmation indicator This indicator lights to confirm that the document is loaded correctly.
2 Lever Turn this lever to clear paper jams.
3 Left cover Open this cover to access the insides of the machine to clear paper
jams.
4 Inner cover Open this cover to access the insides of the machine to clear paper
jams.
5 Document guides Use these guides to align the edges of documents.
6 Document feeder tray Load the originals.
7 Document output tray Delivers scanned documents
8 Document glass Scans the loaded documents.
7
12 3
5
6
4
8
