2 Product Overview
38
Product Overview
2
îš„Telephone Line Connectors
Note • Fax feature is not provided for some models. An optional package is necessary. For more
information, contact our Customer Support Center.
• LINE 2 (line 2) and LINE 4 (line 4) are optional.
No.
Name on the
machine cover
Screen displayed
on the touch
screen while
operating
Function
1 OP.TEL - Use this interface to connect an external telephone
receiver fitted with an extra G3 kit (optional). Do not
connect to the TEL connector; external telephones
cannot be connected to the TEL connector.
2 TEL - Used to connect an external telephone. Do not
connect devices other than telephones. If the "TEL"
connector is covered and you cannot connect a
telephone, contact our Customer Support Center.
3 LINE 1 Line 1 Connected to a public telephone network.
4 LINE 2 Line 2 Connected to a public telephone network.
5 LINE 4 Line 4 Connected to a public telephone network.
5
4
1
2
3
To Next Page
