Fuji Xerox DocuCentre SC2020

9 Tools
160
Tools
9
z
IPsec
Note • IPsec feature is available only when IPsec is enabled on CentreWare Internet Services.
Purpose:
Disables IPsec.
Value:
z
Connection Speed
Note • Connection Speed feature is available only when the machine is connected using the network.
Purpose:
To specify the communication speed and the duplex settings of Ethernet. The change
becomes effective after the machine is turned off and then on again.
Values:
 Protocols
Purpose:
To enable or disable each protocol. The change becomes effective after the machine is
turned off and then on again.
Values:
Gateway Address When an IP address is being set manually, the
gateway address is specified using the format
"nnn.nnn.nnn.nnn". Each octet that makes up
"nnn.nnn.nnn.nnn" is a value in the range of
"0" to "254. "127" and any value in the range
of "224" to "254" cannot be specified for the
first octet of a gateway address.
Disable Disables IPsec.
Auto Detects the Ethernet settings automatically.
10BASE-T Half Uses 10BASE-T Half-duplex.
10BASE-T Full Uses 10BASE-T Full-duplex.
100BASE-TX Half Uses 100BASE-TX Half-duplex.
100BASE-TX Full Uses 100BASE-TX Full-duplex.
LPD Disable Disables the Line Printer Daemon (LPD) port.
Enable Enables the LPD port.
Port9100 Disable Disables the Port9100 port.
Enable Enables the Port9100 port.
FTP Disable Disables FTP port.
Enable Enables FTP port.
IPP Disable Disables IPP port.
Enable Enables IPP port.
WSD Print Disable Disables WSD print.
Enable Enables WSD print.
