● Paper-clipped or stapled documents
● Documents on which the ink is still wet
● Documents smaller than 48 × 50 mm (1.9 × 2.0 in.)
● Documents wider than 240 mm (9.5 in.) (*1)
● Documents other than paper/plastic card (such as fabric, metal foil and OHP film)
● Important documents such as certificates and cash vouchers which must not be damaged
*1:If you use a ballpoint pen to pull out the side guide adjuster and then attach the ADF paper chute (feeder)
to the scanner, documents with a width of up to 240 mm (9.4 in.) can be fed.
For details, refer to Scanning Documents That Are 220 mm to 240 mm in Width (page 178).
ATTENTION
Since carbonless paper contains chemical substances that may harm the brake roller and rollers for feeding
documents (such as the pick roller), the scanner may fail.
How to Load Documents
119

Fujitsu fi-8170 Specifications

General

Duplex scanning	Yes
Maximum scan size	216 x 355.6 mm
ADF scan speed (b/w, A4)	70 ppm
Optical scanning resolution	600 x 600 DPI
Black/white scanning color modes	Grayscale, Monochrome
Control type	Buttons
Scanner type	ADF + Manual feed scanner
Product color	Black, Grey
Sensor type	Dual CIS
Scan drivers	ISIS, TWAIN
Scan file formats	JPEG, PDF, PNG, TIFF
Daily duty cycle (max)	- pages
Scanner smart software features	Blank page detection
Auto document feeder (ADF) input capacity	100 sheets
Card thickness (max)	1.4 mm
Paper tray media weight	20 - 465 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Scanning media types supported	Business Card, Post Card(JPN)
Maximum ISO A-series paper size	A4
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector type	USB Type-B
Input voltage	100 - 240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	28 W
Sustainability certificates	ENERGY STAR, RoHS
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	163 mm
Width	170 mm
Height	300 mm
Weight	4000 g
