Notes When Using IPv6 [fi-8190/fi-8290/fi-8170/fi-8270/fi-8150/fi-8250]

● Scanner settings that do not support IPv6

The following settings do not support IPv6:

● DNS Server

● Proxy Server

● PaperStream NX Manager

● Scanner Central Admin Server

Appendix

431
