Opening/Closing the ADF

This section describes how to open and close the ADF.

How to Open the ADF

1 Remove any documents from the ADF paper chute (feeder).

2 Pull the ADF release tab towards you to open the ADF.

CAUTION

When the ADF is open, it might close accidentally. Be careful not to get your fingers

caught.
