How to Load a Document in the ADF Paper Chute (Feeder)
1 Pull out the chute extensions according to the length of the document.
For details, refer to Setting Up the ADF Paper Chute (Feeder) (page 81).
2 Adjust the stacker according to the length of the documents.
For details, refer to Setting Up the Stacker [fi-8190/fi-8170/fi-8150/fi-8150U] (page 82) or Setting Up the
Stacker [fi-8290/fi-8270/fi-8250/fi-8250U] (page 87).
3 Load a document in the ADF paper chute (feeder).
Load the document face-down in the ADF paper chute (feeder).
ATTENTION
● Remove all paper clips and staples.
● Reduce the number of documents when documents are not fed into the scanner or overlapped
documents are fed.
4 Adjust the side guides to the width of the documents.
Move the side guides so that there is no space between the side guides and the documents.
How to Load Documents
113
