Fujitsu fi-8170

To Next Page

To Previous Page

b Hold both ends of the documents and fan them a few times.

c Rotate the documents by 90 degrees and fan them in the same manner.

d Perform steps a to c for all documents.

e Align the top of the documents.

How to Load Documents

112
