How to Close the ADF

1 Close the ADF.

Push the center of the ADF until it locks in place.

CAUTION

Be careful not to get your fingers caught when closing the ADF.

ATTENTION

Make sure there is no foreign matter caught inside the ADF when closing the ADF.
