Confirm that the ADF is closed properly.
To check whether or not it is closed completely, open the ADF and then close it again.
For more details about opening and closing the ADF, refer to Opening/Closing the ADF (page 77).
Imprinter Cover Open (When the Imprinter Is Installed) [fi-8190/fi-8170/fi-8150/
fi-8150U]
If you open the print section (imprinter cover) while scanning, the following is displayed on the operator panel.
● For the LCD
An error code, error details, and a solution for the problem are displayed on the LCD.
Error Code Error Details and the Solution
U5:4A U5:4A Error
Imprinter Cover Open
● For the Function Number Display
An alphabetical character and a number for the error code are displayed alternately on the Function Number
Display.
Error Code Error Details (displayed in the Error Recovery Guide window)
U5 Imprinter Cover Open
HINT
If you open the print section (imprinter cover) while the scanner is in standby, the following is displayed on
the operator panel.
● For fi-8190/fi-8170
Only an error message appears on the LCD without an error code
● For fi-8150/fi-8150U
"c" which is displayed on the Function Number Display and the LED indicator flashes alternately.
Remove the document from the ADF, and close the print section (imprinter cover).
Confirm that the print section (imprinter cover) is closed properly.
To check whether or not it is closed completely, open the print section (imprinter cover) and then close it again.
For details about opening and closing the print section (imprinter cover), refer to the fi-819PRB Imprinter
Operator's Guide.
Print Cartridge Not Installed (When the Imprinter Is Installed) [fi-8190/fi-8170/
fi-8150/fi-8150U]
If the print cartridge is not installed in the imprinter, the following is displayed on the operator panel.
● For the LCD
An error code, error details, and a solution for the problem are displayed on the LCD.
Troubleshooting
276
