Fujitsu fi-8170 - Installation Specification

Installation Specification
Item Specification
Outer dimensions (W × D × H) (*1)
● For fi-8190/fi-8170/fi-8150/fi-8150U
300 × 170 × 163 mm/11.81 × 6.69 × 6.42
in
● For fi-8290/fi-8270/fi-8250/fi-8250U
300 × 577 × 234 mm/11.81 × 22.72 ×
9.21 in.
Installation space (W × D × H) (*2)
● For fi-8190/fi-8170/fi-8150/fi-8150U
400 × 700 × 440 mm/15.75 × 27.56 ×
17.32 in.
● For fi-8290/fi-8270/fi-8250/fi-8250U
400 × 800 × 570 mm/15.75 × 31.50 ×
22.44 in.
Weight
● For fi-8190/fi-8170/fi-8150/fi-8150U
4 kg (8.82 lb)
● For fi-8290/fi-8270/fi-8250/fi-8250U
8.8 kg (19.40 lb)
Input power Voltage range AC 100 to 240 V ±10%
Phase Single phase
Frequency range 50/60 Hz ±3 Hz
Power consumption Operating
● For fi-8190/fi-8290
30 W or less (17 W in ECO Mode)
● For fi-8170/fi-8270
28 W or less (17 W in ECO Mode)
● For fi-8150/fi-8250/fi-8150U/fi-8250U
21 W or less (17 W in ECO Mode)
Power saving
● For fi-8190/fi-8290/fi-8170/fi-8270/
fi-8150/fi-8250
For wired LAN connection: 2.0 W or less
For USB connection: 1.4 W or less
● For fi-8150U/fi-8250U
For wired LAN connection: None
For USB connection: 1.4 W or less
Power off 0.2 W or less
Ambient conditions Temperature Operating: 5 to 35℃ (41 to 95°F)
Not operating: -20 to 60℃ (-4 to 140°F)
Appendix
423
