Fujitsu fi-8170 User Manual

Documents with Different Sizes
1 Adjust the stacker to fit the longest document.
For details, refer to Document Length Is A5 (Portrait) or Longer (page 87).
2 Pinch the stack supporter and pull it out.
ATTENTION
● Do not apply too much force to the stack supporter after pulling it out, because it may break.
● Documents that are damaged easily, such as thin paper documents, may not stack neatly when they are
ejected because the stack supporter may prevent documents from ejecting fully or may cause documents
to curl.
HINT
● When scanning documents including documents smaller than A6 size, using the stack supporter
prevents documents from scattering.
Basic Operations
91

Fujitsu fi-8170 Specifications

General

Duplex scanning	Yes
Maximum scan size	216 x 355.6 mm
ADF scan speed (b/w, A4)	70 ppm
Optical scanning resolution	600 x 600 DPI
Black/white scanning color modes	Grayscale, Monochrome
Control type	Buttons
Scanner type	ADF + Manual feed scanner
Product color	Black, Grey
Sensor type	Dual CIS
Scan drivers	ISIS, TWAIN
Scan file formats	JPEG, PDF, PNG, TIFF
Daily duty cycle (max)	- pages
Scanner smart software features	Blank page detection
Auto document feeder (ADF) input capacity	100 sheets
Card thickness (max)	1.4 mm
Paper tray media weight	20 - 465 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Scanning media types supported	Business Card, Post Card(JPN)
Maximum ISO A-series paper size	A4
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector type	USB Type-B
Input voltage	100 - 240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	28 W
Sustainability certificates	ENERGY STAR, RoHS
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	163 mm
Width	170 mm
Height	300 mm
Weight	4000 g
