Connecting the Scanner via a Wired LAN in order to Operate It with PaperStream
NX Manager (When Assigning an IP Address Manually) [fi-8190/fi-8290/fi-8170/
fi-8270/fi-8150/fi-8250]
This section explains about the setup procedure for you to connect the scanner to a network device via a wired LAN
in order to operate the scanner with PaperStream NX Manager and manually assign an IP address to the scanner.
For the procedure to unpack the scanner, refer to Getting Started.
ATTENTION
If an old version of the software is installed, uninstall it first.
For the procedure to uninstall the software, refer to Uninstalling the Software (page 429).
HINT
Install the necessary software to operate the scanner with PaperStream NX Manager by referring to the
PaperStream NX Manager User's Guide.
Use the Setup DVD-ROM to configure the network settings of the scanner.
1 Turn on the computer and log onto Windows as a user with administrator privileges.
The computer is used to set up the scanner so that it can be operated with PaperStream NX Manager.
2 Insert the Setup DVD-ROM into the DVD drive.
The [fi Series Setup] window appears.
HINT
If the [fi Series Setup] window does not appear, double-click "Setup.exe" in the Setup DVD-ROM via [File
Explorer] or [Computer].
3 Click the scanner model name to be used (if the window for selecting a model name is displayed).
4 Click the [Installation (Custom)] button.
Scanner Setup
65
To Next Page
