Fujitsu fi-8170 User Manual

Scanning Long Page Documents
Documents with a length up to 6,096 mm (240 in.) can be scanned by long page scanning.
Depending on the resolution setting or the image scanning application, the document sizes that can be scanned
may differ.
For details, refer to the help for your scanner driver and the manual/help for your image scanning application.
1 Pull out the chute extensions all the way.
For details, refer to Setting Up the ADF Paper Chute (Feeder) (page 81).
2 Adjust the stacker.
For details, refer to Setting Up the Stacker [fi-8190/fi-8170/fi-8150/fi-8150U] (page 82) or Setting Up the
Stacker [fi-8290/fi-8270/fi-8250/fi-8250U] (page 87).
3 Load a document in the ADF paper chute (feeder).
For details, refer to How to Load a Document in the ADF Paper Chute (Feeder) (page 113).
ATTENTION
Long page documents should be loaded one sheet at a time in the ADF paper chute (feeder).
4 In the scanner driver, configure the scan settings to scan the paper size of the long page.
For details, refer to the help for the scanner driver.
For some image scanning applications, the setup window for the scanner driver may not appear.
5 Scan the document with the image scanning application.
For details, refer to the manual/help of the image scanning application.
ATTENTION
When scanning a long page document, support the document with your hand so that it does not fall off.
For details, refer to How to Load a Document in the ADF Paper Chute (Feeder) (page 113).
Various Ways to Scan
197

Fujitsu fi-8170 Specifications

General

Duplex scanning	Yes
Maximum scan size	216 x 355.6 mm
ADF scan speed (b/w, A4)	70 ppm
Optical scanning resolution	600 x 600 DPI
Black/white scanning color modes	Grayscale, Monochrome
Control type	Buttons
Scanner type	ADF + Manual feed scanner
Product color	Black, Grey
Sensor type	Dual CIS
Scan drivers	ISIS, TWAIN
Scan file formats	JPEG, PDF, PNG, TIFF
Daily duty cycle (max)	- pages
Scanner smart software features	Blank page detection
Auto document feeder (ADF) input capacity	100 sheets
Card thickness (max)	1.4 mm
Paper tray media weight	20 - 465 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Scanning media types supported	Business Card, Post Card(JPN)
Maximum ISO A-series paper size	A4
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector type	USB Type-B
Input voltage	100 - 240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	28 W
Sustainability certificates	ENERGY STAR, RoHS
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	163 mm
Width	170 mm
Height	300 mm
Weight	4000 g
