No. Name Function
6 [Scan/Enter] button Starts scanning.
Pressing this button during scanning pauses the scan.
This button is also used to eject a document or configure
settings for the operations of the scanner on the LCD.
Lights in green when the scanner is on.
Flashes in green when the scanner enters power saving
mode.
Flashes in green three times when the feed mode is
switched to Manual Feed Mode.
7 [Stop/Clear] button Stops scanning.
This button is also used to clear an error on the screen of
the LCD, return to the previous screen while configuring
the scanner, and clear the page counter (when pressed
down for three seconds or longer).
*1:For information on how to scan documents with the [Manual Feed] button, refer to the following.
● Scanning Documents Folded in Half (page 181)
● Scanning Documents such as Envelopes or Multi-Layered Transfer Paper (page 184)
● Scanning Booklets such as Passports (page 187)
● Feeding Documents Manually (page 202)
ATTENTION
Do not use the operator panel while the Software Operation Panel is running.
HINT
For information on how to use the operator panel when operating PaperStream NX Manager, refer to
Processing a Job (With PaperStream NX Manager) [fi-8190/fi-8290/fi-8170/fi-8270] (page 106).
How to Use the Operator Panel [fi-8190/fi-8290/fi-8170/fi-8270]
139
