3 Press the [ ] button/[ ] button to select [Information], and then press the [Scan/Enter] button.

The [Information] screen is displayed on the LCD.

ATTENTION

[Information] can be selected only when there is a message for replacing consumables/cleaning/glass

cleaning/regular maintenance.

4 Press the [ ]/[ ] button and check the contents of the information.

You can check messages for consumable replacement/cleaning/glass cleaning/maintenance.

When the message prompts replacing consumables/cleaning, the corresponding counter that requires

consumable replacement/cleaning is highlighted.

Counters will appear highlighted when:

● The page count after the consumable is replaced reaches 95% of the value configured in Specifying the

Cycle to Replace Consumables [Life Counter Alarm Setting] (page 358) in the Software Operation Panel.

(For the brake roller/pick roller counters)

● The page count after cleaning reaches the value configured in Scanner Cleaning Cycle [Cleaning Cycle]

(page 357) in the Software Operation Panel. (For the cleaning counter)

● The amount of remaining ink is below 33%. This is only displayed when the imprinter is installed. (For the

ink counter)

5 Take measures according to the contents of [Information].

Follow the instructions in the message if it prompts consumable replacement/cleaning/glass cleaning.

For details about replacing consumables, refer to the following:

● Replacing the Pick Roller (page 238)

● Replacing the Brake Roller (page 233)

For details about cleaning, refer to Daily Care (page 214).

If the message prompts regular maintenance, please have the scanner checked by a service engineer for

regular maintenance/inspection.

For regular maintenance and inspection on the scanner by a service engineer, contact the distributor/dealer

where you purchased this product. Refer to the contact information in the Contact List if supplied with this

product, or refer to the contact information in the Contact for Inquiries section if provided in Safety

Precautions supplied with this product, and then make an inquiry.

How to Use the Operator Panel [fi-8190/fi-8290/fi-8170/fi-8270]

152

Fujitsu fi-8170 Specifications

General

Duplex scanning	Yes
Maximum scan size	216 x 355.6 mm
ADF scan speed (b/w, A4)	70 ppm
Optical scanning resolution	600 x 600 DPI
Black/white scanning color modes	Grayscale, Monochrome
Control type	Buttons
Scanner type	ADF + Manual feed scanner
Product color	Black, Grey
Sensor type	Dual CIS
Scan drivers	ISIS, TWAIN
Scan file formats	JPEG, PDF, PNG, TIFF
Daily duty cycle (max)	- pages
Scanner smart software features	Blank page detection
Auto document feeder (ADF) input capacity	100 sheets
Card thickness (max)	1.4 mm
Paper tray media weight	20 - 465 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Scanning media types supported	Business Card, Post Card(JPN)
Maximum ISO A-series paper size	A4
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector type	USB Type-B
Input voltage	100 - 240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	28 W
Sustainability certificates	ENERGY STAR, RoHS
Harmonized System (HS) code	84716070
