Fujitsu fi-8170

To Next Page

To Previous Page

The Software Operation Panel exits [View Only mode], and the scanner settings can now be changed.

HINT

When the Software Operation Panel exits [View Only mode], the check mark next to [View Only mode]

disappears from the menu that is displayed by right-clicking the Software Operation Panel icon in the notification

area.

Scanner Settings (Software Operation Panel)

339
