Fujitsu PRIMERGY RX4770 M5 User Manual

Tools:
– Phillips PH1 / (+) No. 1 screw driver
–
Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Locating the defective server" on page
43.
▶
"Suspending BitLocker functionality" on page 85.
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
"Extending the server out of the rack" on page 48.
▶
"Removing the server from the rack" on page 49.
▶
"Removing the top covers" on page 51.
▶
Remove the air duct from the top system board, see "Removing the CPU
air duct" on page 72.
▶
"Removing the fan cage" on page 69.
▶
"Removing the riser module 3/4 and 6/7" on page 61.
▶
"Removing the top system board holder" on page 74.
▶
Remove the air duct from the bottom system board, see "Removing the
CPU air duct" on page 72.
▶
Disconnect the mini-SAS cable near the power distribution board from the
bottom system board.
▶
If applicable, remove the RAID card, see "Removing an expansion card" on
page 209.
▶
Remove the riser module in slot 5, see "Removing the riser module" on
page 64.
▶
Disconnect the VGA cable from the bottom system board, see "Removing
the front panel module" on page 305.
▶
Remove all hot-plug PSUs, see "Removing a hot-plug PSU" on page 125.
Power supply unit (PSU)
RX4770 M5 Upgrade and Maintenance Manual 131
