Preliminary steps
▶
"Suspending BitLocker functionality" on page
85.
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 47.
▶
For Slot 3, 4, 5, 6 and 7: Remove the corresponding riser module, see
"Handling riser modules" on page 60.
If you do not want to use the riser module 3/4, 6/7, or another riser
module, you do not need to remove any other components beside the
housing cover
.
Removing the slot cover
Figure 91: Removing the slot cover - example: riser module 3/4
▶
Remove the slot cover
.
CAUTION
▶
Keep the slot cover for future use. If the expansion card is removed
and not replaced with a new one, the slot cover must be installed
again due to cooling, to comply with applicable EMC regulations
and to protect against fire.
Expansion cards and backup units
RX4770 M5 Upgrade and Maintenance Manual 191
