at:
https://www
.fujitsu.com/jp/products/computing/servers/primergy/
▶
Click 「ダウンロード」.
▶
Click 「ダウンロード検索」.
▶
Click on your PRIMERGY system to select it.
▶
Select 「ファームウェア」 and click「検索開始」.
In the next screen, you can find BIOS.
For memory slots from A to M valid for the bottom system board.
Field Replaceable Unit
(FRU)
Hardware: 20 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver (for housing cover)
For memory slots from N to Z valid for the top system board.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver (for housing cover)
Preliminary steps
For memory slots from A to M valid for the bottom system board.
▶
"Suspending BitLocker functionality" on page
85.
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
"Removing the server from the rack" on page 49.
▶
"Getting access to the component" on page 47.
▶
Remove the air duct from the top system board, see "Removing the CPU
air duct" on page 72.
▶
"Removing the fan cage" on page 69.
▶
"Removing the riser module 3/4 and 6/7" on page 61.
Main memory
258 Upgrade and Maintenance Manual RX4770 M5
