Installing the Dual microSD 64GB Enterprise
Figure 192: Connecting the cable to the Dual microSD 64GB Enterprise
â–¶
Connect the cable to connector "CON2" on the Dual microSD 64GB
Enterprise.
Figure 193: Installing the microSD card
â–¶
Install the microSD card on the top side (1) or on the bottom side (2) or in
both sides in the corresponding slot. For the installation of the microSD card,
see "Replacing the Dual microSD 64GB Enterprise" on page
349.
System board and components
RX4770 M5 Upgrade and Maintenance Manual 345
