Page #135 background imageLoading...
Page #135 background image
Field Description
flow over the RTS and CTS lines.
• XON/XOFF: If the software handshake is used, the recipient
sends special signs to the sender to control the data flow.
Fields in the Serial PortIP menu
Field Description
Mode
Select the mode in which the gateway should process IP data
packets.
Possible values:
• Server (default value): The gateway waits for incoming TCP
connections.
• Client: The gateway actively sets up a TCP connection.
• UDP: The gateway sends and receives UDP packets.
Local IP Address
Enter the IP address of the client logging in. If Local IP Ad-
dress = 0.0.0.0, any client can log in.
Local Port
Enter the port for the Local IP Address.
Remote IP
Enter the IP address of the server at which your gateway should
log in.
Port number
Enter the port for the Remote IP.
Fields in the Serial PortTrigger menu
Field Description
Byte number
Enter the received characters in bytes, which are used as a trig-
ger for data transmission.
The function is activated with Enabled.
The function is enabled by default.
Possible values: 1 1460. Default value: 128.
Timeout
Enter the time in ms since receiving the last character, which is
used as a trigger for data transmission.
The function is activated with Enabled.
Funkwerk Enterprise Communications GmbH
9 Physical interfaces
bintec W1002/W1002n/W2002/WIx040/WIx065 123
