Field Description
• 802.11a: The device operates only in accordance with
802.11a.
• 802.11n: Your device operates only according to 802.11n.
• 802.11 a/n: Your device operates according to either
802.11a or 802.11n.
Max. Transmission Rate Select the transmission speed.
Possible values:
• Automatic (default value): The transmission speed is de-
termined automatically.
• <Value>: 1,2, 5, 6, 9, 11, 12, 18, 24, 36, 48, 54 mbps. In
bintec W1002n different fixed values in mbps are offered for
selection depending on the setting for Operation Band,
Bandwidth, Number of Spatial Streams and Wireless
Mode.
Nitro Mode Only for bintec W1002, bintec W2002, bintec WIx040, bintec
WIx060
Activate this function to increase the transmission speed for
802.11g through frame bursting. As a result, several packets
are sent one after the other without a waiting period. This is par-
ticularly effective in 11b/g mixed operation.
The function is activated with Enabled.
The function is activated by default.
If problems occur with older WLAN hardware, this function
should be deactivated.
Nitro XM Only for bintec W1002, bintec W2002, bintec WIx040, bintec
WIx060
The Nitro XM (eXtreme Multimedia) function can increase
throughput by combining Protection (avoids collisions in radio
cells with 11g and 11b clients), Packet Bursting (sending of sev-
eral data packets together; already implemented with the name
Nitro), Compression and Concatenation (combines several
smaller packets into one larger WLAN packet).
Possible values:
11 Wireless LAN Funkwerk Enterprise Communications GmbH
146 bintec W1002/W1002n/W2002/WIx040/WIx065
